Improved Performance Extended Service Life with Flammability Testing Equipment
Application:
Rod forging, rod hardening.
bolt,nut forging
heat treatment of shaft, gear, pin, etc.
shrink-fitting
annealing of pipe and steel wire
Pipe bending.
Brazing.
etc.
Parameter
| item | value |
| place of Origin | China |
| Brand Name | YUYANG |
| Condition | New |
| Machine Type | Induction Heating Machine |
| Machinery TestReport | Provided |
| Marketing Type | New Product 2021 |
| Warranty of core components | 1 Year |
| Core Components | PLC, Motor |
| Warranty | 1 Year |
| Key Selling Points | Easy to Operate |
| After Warranty Service | Video technical support, Online support |
| Local Service Location | Malaysia, Saudi Arabia, Pakistan, India |
| Applicable Industries | Machinery Repair Shops, Manufacturing Plant, Other |
| Showroom Location | None |
| Rated Power output | 60kw |
| Work power | 340V-430V |
| Maximum input cur | 10-70A |
| Volume(mm 3) | 660 mmx290mmx410mm 740 mmx340mmx380mm |
| Max input current | 200-1200A |
| Gross weight | Host 54kg Extension 43kg |
| Power supply | Three phase 380v 50Hz |
| Time sting(atomatic time) | 1-99.02s |
| Cooling water | 0.08-0.16MPa 9L/min |
Main characteristics:
1. IGBT inversion technology based LC series circuit .
2. phase locking looping technology and soft switch ensure good reliability, realize power and frequency tracking automatically.
3. diode rectifier cause high power factor more than 0.95
4. working continuously with 100% duty cycle, power can be instantly turned on or shut off.
5. perfect protective circuit and cooling system design, which ensure the good reliability of machine.
6. low energy consumption: converts up to 97.5% above of the expended energy into useful heat. energy saving 15%-30% compared with SCR induction heating machine.
7. environment friendly, clean, non-polluting process which will help protect the environment, improves working conditions for your employees by eliminating smoke, waste heat, noxious emissions and loud noise.
8. operating and installation easily and safely
9. can subsititue traditional heating methods.
Advantages of Induction Heating Equipment
1. Rapid Heating: The minimum heating time is under 1 second, and the heating rate is adjustable and controllable.
2. Broad Heating Application: Suitable for heating various metal parts. You can replace the removable induction coil according to different operation requirements.
3. Simple Installation: Just connect it to the power source, induction coil, water supply pipe, and return pipe, and it's ready to use. It is compact in size and lightweight.
4. User-friendly Operation: You can master its operation within a few minutes.
5. Quick Start-up: It can start heating immediately as long as water and power are available.
6. Low Power Consumption: Compared with traditional vacuum tube high-frequency equipment, it can save about 70% of the power. Smaller workpieces consume even less power.
7. High Efficiency: It features uniform heating (you can adjust the spacing of the induction coil to ensure the proper temperature for each part of the workpiece), rapid warming, and a limited oxidation layer, preventing any post-annealing waste.
8. Comprehensive Protection: Equipped with functions like overpressure, overcurrent, overheat, and water shortage alarm indications, along with automatic control and protection.
9. Precise Temperature Control: You can control the heating temperature of workpieces according to the preset heating time, thus maintaining the temperature at a specific technical level.
10. Full Load Design: Capable of continuous 24-hour operation.
